Part No: SCMP-H-6D-1500-MINI

Specification

Excursion	Range	Velocity	Acceleration
Pitch	±250	350/s	2500/s2
Roll	±250	350/s	2500/s2
Yaw	±180	350/s	2500/s2
Heave	±160mm	450mm/s	0.8g
Surge	±160mm	450mm/s	0.8g
Sway	±160mm	450mm/s	0.8g
Payload	1500kg

---

Part No: SCMP-H-6D-2000

Specification

Excursion	Range	Velocity	Acceleration
Pitch	±250	450/s	2500/s2
Roll	±250	450/s	2500/s2
Yaw	±200	450/s	2500/s2
Heave	±190mm	500mm/s	0.8g
Surge	±190mm	500mm/s	0.8g
Sway	±190mm	500mm/s	0.8g
Payload	2000kg

---

Part No: SCMP-EM-6D-1500

Specification

Excursion	Range	Velocity	Acceleration
Pitch	±200	300/s	2500/s2
Roll	±200	300/s	2500/s2
Yaw	±250	400/s	2500/s2
Heave	±200mm	400mm/s	0.8g
Surge	±260mm	500mm/s	0.8g
Sway	±260mm	500mm/s	0.8g
Payload	1500kg

---

Part No: SCMP-H-6D-350

Specification

Excursion	Range	Velocity	Acceleration
Pitch	±300	350/s	6500/s2
Roll	±350	350/s	6500/s2
Yaw	±300	350/s	6500/s2
Heave	±350mm	450mm/s	0.8g
Surge	±400mm	450mm/s	0.8g
Sway	±400mm	450mm/s	0.8g
Payload	350kg

---

Part No: SCMP-EM-6D-250

Specification

Excursion	Range	Velocity	Acceleration
Pitch	±300	350/s	2500/s2
Roll	±280	350/s	2500/s2
Yaw	±300	350/s	2500/s2
Heave	±270mm	450mm/s	0.8g
Surge	±250mm	450mm/s	0.8g
Sway	±250mm	450mm/s	0.8g
Payload	250kg

---

Part No: SCMP-EM-6D-250

Specification

Excursion	Range	Velocity	Acceleration
Pitch	±250	350/s	2500/s2
Roll	±250	350/s	2500/s2
Yaw	±200	350/s	2500/s2
Heave	±250mm	450mm/s	0.8g
Surge	±250mm	450mm/s	0.8g
Sway	±250mm	450mm/s	0.8g
Payload	250kg

---

Part No: SCMP-EM-7D-500

Specification

Excursion	Range	Velocity	Acceleration
Pitch	±250	350/s	2500/s2
Roll	±250	350/s	2500/s2
Yaw	±200	350/s	2500/s2
Heave	±250mm	450mm/s	0.8g
Surge	±250mm	450mm/s	0.8g
Sway	±250mm	450mm/s	0.8g
Azimuth	±3600	2000/s	5000/s2
Payload	500kg
