Directional Valves
- Industry-common cavity sizes -04, -08, -10, -12, -16, -20 and -42
- Hydraulically piloted or manually-operated directional and logic valves enable circuit flexibility and performance optimization
- Proportional, piloted 3-position, 4-way directional valves for flow rates up to 170 lpm (45 gpm)
- Hardened precision seats, spools and cages for long life and low leakage
Brake release valve
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| BV10-40 | 240 (3500) | 8 (2) |
Check valve
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| CV08-21 | 240 (3500) | 30 (8) |
| CV12-21 | 240 (3500) | 114 (30) |
| CV10-24 | 240 (3500) | 57 (15) |
Pilot Operated Check Valve Dual
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| DC10-40 | 240 (3500) | 30 (8) |
Brake release valve, 2-position, 3-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| BV10-42 | 240 (3500) | 8 (2) |
Check valve
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| CV10-28 | 240 (3500) | 45 (12) |
Pilot operated check valve with thermal relief, dual cartridges in manifold
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|
Check valve
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| CV04-20 | 240 (3500) | 5 (1.5) |
| CV04-B20 | 240 (3500) | 5 (1.3) |
| HCV06-20 | 350 (5075) | 19 (5) |
| CV08-20 | 240 (3500) | 30 (8) |
| HCV08-20 | 350 (5075) | 30 (8) |
| CV10-20 | 240 (3500) | 75 (20) |
| CV50-20 | 345 (5000) | 57 (15) |
| CV12-20 | 240 (3500) | 95 (25) |
| HCV12-20 | 350 (5075) | 95 (25) |
| CV16-20 | 240 (3500) | 151 (40) |
| HCV16-20 | 350 (5075) | 151 (40) |
| CV42-M20 | 240 (3500) | 378 (100) |
| HCV42-M20 | 350 (5075) | 303 (80) |
Check valve disk
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| CVD08 | 250 (3625) | 1.9 (0.5) |
| CVD10 | 250 (3625) | 1.9 (0.5) |
Relief valve, direct acting with anticavitation check
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| DCV10 | 240 (3500) | 76 (20) |
Proportional directional valve, 2-position, 4-way, normally closed, isolated load sense port
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| DC08-40 | 240 (3500) | 19 (5) |
Logic element, spool type, 2-position, 2-way, externally piloted
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| EP08-35 | 345 (5000) | 38 (10) |
| EP10-S35 | 345 (5000) | 76 (20) |
| EP12-S35 | 345 (5000) | 151 (40) |
| EP16-S35 | 240 (3500) | 189 (50) |
| HEP16-S35 | 350 (5075) | 190 (50) |
| EP20-S35 | 345 (5000) | 379(100) |
| HEP42-S35 | 350 (5075) | 379(100) |
Low side (hot oil) shuttle valve
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HS50-43 | 345 (5000) | 132 (35) |
| HS52-43 | 345 (5000) | 113 (30) |
Manual 2-position, 4-way valve, push to shift, spring return
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MD10-40 | 207 (3000) | 38 (10) |
Logic element, poppet type, 2-position, 2-way, externally piloted
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| EP10-S38 | 350 (5075) | 114 (30) |
| EP20-S38 | 240 (3500) | 303 (80) |
| HEP42-S38 | 350 (5075) | 284 (75) |
Load shuttle, ball type, down-hole mount
| LS04-B30 | 240 (3500) | 5 (1.3) |
| HLS06-B30 | 350 (5075) | 8 (2) |
Manual 2-position, 2-way valve, pull to open, spring return
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP08-20 | 207 (3000) | 53 (14) |
| MP10-20 | 207 (3000) | 57 (15) |
Logic element, poppet type, 2-position, 2-way, externally piloted
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| EP20-S39 | 240 (3500) | 285 (75) |
| HEP42-S39 | 350 (5075) | 284 (75) |
Load shuttle, ball type
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HLS06-30 | 350 (5075) | 8 (2) |
| LS08-30 | 240 (3500) | 19 (5) |
| LS10-30 | 240 (3500) | 30 (8) |
| LS50-30 | 345 (5000) | 30 (8) |
Manual 2-position, 2-way valve, pull to open, with lock
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP10-22 | 207 (3000) | 57 (15) |
Logic element, spool type, vented
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| EV58-34 | 345 (5000) | 38 (10) |
| EV10-S34 | 345 (5000) | 76 (20) |
| EV12-S34 | 345 (5000) | 151 (40) |
| EV16-S34 | 240 (3500) | 189 (50) |
| HEV16-S34 | 350 (5075) | 190 (50) |
| EV20-S34 | 345 (5000) | 379 (100) |
| HEV42-S34 | 350 (5075) | 379 (100) |
Load shuttle network, 3 branch
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| LS10-40 | 240 (3500) | 1.9 (0.5) |
Low side (hot oil) shuttle valve, springless
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HS10-42 | 207 (3000) | 38 (10) |
| HS50-42 | 207 (3000) | 38 (10) |
| HS52-42 | 345 (5000)45 (12) |
Load shuttle, inverted
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| LS10-41 | 240 (3500) | 15 (4) |
Manual 2-position, 4-way valve, pull to shift, spring return, open transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP08-40 | 240 (3500) | 12 (3) |
| MP10-40 | 207 (3000) | 22 (6) |
Load shuttle network, 4 branch
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| LS10-50 | 240 (3500) | 1.9 (0.5) |
Manual 2-position, 4-way valve, pull to shift, spring return, closed transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP08-41 | 240 (3500) | 12 (3) |
| MP10-41 | 207 (3000) | 12 (3) |
Manual 3-position, 4-way valve, push/ pull operation, closed center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP10-47C | 207 (3000) | 23 (6) |
Manual rotary, 2-position, 4-way valve, blocked transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-41 | 240 (3500) | 11 (3) |
Manual 2-position, 4-way valve, pull to shift, spring return, closed transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP10-42 | 207 (3000) | 12 (3) |
Manual 3-position, 4-way valve, push/pull operation, motor center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP10-47D | 207 (3000) | 23 (6) |
Manual rotary, 2-position, 4-way valve, open transition, port 4 blocked
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-43 | 240 (3500) | 11 (3) |
Manual 2-position, 4-way valve, pull to shift, spring return, open transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP10-43 | 207 (3000) | 12 (3) |
Manual rotary, 2-position, 3-way valve, blocked transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-31 | 240 (3500) | 38 (10) |
Manual rotary, 3-position, 4-way valve, tandem center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-47A | 240 (3500) | 11 (3) |
Manual 3-position, 4-way valve, push/ pull operation, tandem center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP10-47A | 207 (3000) | 15 (4) |
Manual rotary, 3-position, 3-way valve, closed cente
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-37A | 240 (3500) | 38 (10) |
Manual rotary, 3-position, 4-way valve, open center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-47B | 240 (3500) | 11 (3) |
Manual 3-position, 4-way valve, push/pull operation, open center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MP10-47B | 207 (3000) | 11 (3) |
Manual rotary, 3-position, 3-way valve, open cente
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-37B | 240 (3500) | 38 (10) |
Manual rotary, 3-position, 4-way valve, closed center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-47C | 240 (3500) | 11 (3) |
Manual rotary, 2-position, 4-way valve, blocked transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-40 | 240 (3500) | 11 (3) |
Manual rotary, 3-position, 4-way valve, motor cente
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-47D | 240 (3500) | 11 (3) |
Manual rotary, 3-position, 4-way valve, tandem center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-47F | 240 (3500) | 11 (3) |
Spool valve, piloted, 2-position, 2-way, normally open, external vent
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-30 | 240 (3500) | 38 (10) |
| PD12-30 | 240 (3500) | 113 (30) |
Spool valve, piloted, 2-position, 3-way, internal vent, open transition
| PD10-41 | 240 (3500) | 45 (12) |
| PD12-41 | 240 (3500) | 113 (30) |
| PD16-41 | 240 (3500) | 189 (50) |
| PD42-M41 | 345 (5000) | 265 (70) |
Manual rotary, 3-position, 4-way valve, motor center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MR10-47G | 240 (3500) | 11 (3) |
Spool valve, piloted, 2-position, 2-way, normally closed, internal vent
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-32 | 240 (3500) | 38 (10) |
| PD12-32 | 240 (3500) | 113 (30) |
Spool valve, piloted, 2-position, 3-way, internal vent, open transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-42 | 240 (3500) | 38 (10) |
| PD12-42 | 240 (3500) | 113 (30) |
| PD16-42 | 240 (3500) | 189 (50) |
| PD42-M42 | 345 (5000) | 265 (70) |
Manual valve, push to open
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| MV06-20 | 240 (3500) | 115 (30) |
| MV08-22 | 207 (3000) | 38 (10) |
Spool valve, piloted, 2-position, 2-way, normally closed, external vent
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-34 | 240 (3500) | 38 (10) |
| PD12-34 | 240 (3500) | 113 (30) |
Spool valve, piloted, 2-position, normally closed
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-44 | 240 (3500) | 32 (8) |
| PD12-44 | 240 (3500) | 113 (30) |
| PD16-44 | 240 (3500) | 189 (50) |
| HPD42-M44 | 350 (5075) | 265 (70) |
Check, pilot to open
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PCV10 | 240 (3500) | 60 (16) |
| HPCV16 | 350 (5075) | 151 (40) |
| PCV16 | 240 (3500) | 151 (40) |
Spool valve, piloted, 2-position, 3-way, external vent
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-40 | 240 (3500) | 38 (10) |
| PD12-40 | 240 (3500) | 113 (30) |
| PD16-40 | 240 (3500) | 170 (45) |
| PD42-M40 | 345 (5000) | 265 (70) |
Spool valve, piloted, 2-position, normally open
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-45 | 240 (3500) | 45 (12) |
| PD12-45 | 240 (3500) | 113 (30) |
| PD16-45 | 240 (3500) | 189 (50) |
| PD42-M45 | 345 (5000) | 265 (70) |
| HPD42-M45 | 350 (5075) | 265 (70) |
Spool valve, piloted, 2-position, 3-way, open transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-50 | 240 (3500) | 38 (10) |
Spool valve, piloted, 2-position, 3-way, open transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD12-S50 | 240 (3500) | 95 (25) |
| HPD16-S50 | 350 (5075) | 151 (40) |
| PD16-S50 | 240 (3500) | 170 (45) |
| PD42-S50 | 345 (5000) | 265 (70) |
| HPD42-S50 | 350 (5075) | 265 (70) |
Spool valve, piloted, 2-position, 3-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-51 | 240 (3500) | 45 (12) |
| HPD16-S51 | 350 (5075) | 151 (40) |
| PD16-S51 | 240 (3500) | 151 (40) |
| HPD42-S51 | 240 (3500) | 246 (65) |
Spool valve, piloted, 2-position, 3-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HPD16-S52 | 350 (5075) | 151 (40) |
| HPD42-S52 | 350 (5075) | 265 (70) |
Spool valve, piloted, 2-position, 4-way, open transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD12-S60N | 345 (5000) | 56 (15) |
Spool valve, piloted, 2-position, 4-way, open transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD16-S60N | 240 (3500) | 95 (25) |
| PD42-S60N | 324 (4700) | 189 (50) |
Spool valve, piloted, 2-position, 4-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HPD42-S61 | 350 (5075) | 189 (50) |
Spool valve, piloted, 2-position, 4-way, open transition
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD12-S61N | 240 (3500) | 56 (15) |
| PD16-S61N | 240 (3500) | 151 (40) |
Spool valve, piloted, 2-position, 4-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD10-S62 | 250 (3625) | 53 (14) |
| HPD42-S62 | 350 (5075) | 189 (50) |
Spool valve, piloted, 2-position, 4-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD16-S63 | 240 (3500) | 151 (40) |
| HPD42-S63 | 350 (5075) | 189 (50) |
Spool valve, piloted, 3-position, 4-way, open center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD42-S67B | 324 (3625) | 189 (50) |
Spool valve, piloted, 3-position, 4-way, closed center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD16-S67C | 240 (3500) | 95 (25) |
| HPD16-S67C | 350 (5075) | 95 (25) |
| HPD42-S67C | 350 (5075) | 189 (50) |
Spool valve, piloted, 3-position, 4-way, motor center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PD16-S67D | 240 (3500) | 95 (25) |
| HPD16-S67D | 350 (5075) | 95 (25) |
| HPD42-S67D | 350 (5075) | 189 (50) |
Spool valve, piloted, 2-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HPE42-M44 | 350 (5075) | 170 (45) |
Spool valve, piloted, 2-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HPE42-M45 | 350 (5075) | 170 (45) |
Spool valve, piloted, proportional, 3-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HPE42-S50 | 350 (5075) | 170 (45) |
Spool valve, piloted, proportional, 3-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HPE42-S51 | 350 (5075) | 170 (45) |
Spool valve, piloted, proportional, 3-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HPE42-S52 | 350 (5075) | 170 (45) |
Spool valve, piloted, proportional, 4-way
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| HPE42-S62 | 350 (5075) | 170 (45) |
Spool valve, piloted, proportional, 3-position, 4-way, closed center
US Pat. 6,554,014| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PE12-S67C | 345 (5000) | 45 (12) |
| HPE16-S67C | 350 (5075) | 95 (25) |
| PE16-S67C | 345 (5000) | 90 (24) |
| HPE42-S67C | 350 (5075) | 170 (45) |
| PE42-S67C | 345 (5000) | 170 (45) |
Spool valve, piloted, proportional, 3-position, 4-way, motor center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PE12-S67D | 345 (5000) | 45 (12) |
| HPE16-S67D | 350 (5075) | 95 (25) |
| PE16-S67D | 345 (5000) | 90 (24) |
| PE42-S67D | 345 (5000) | 170 (45) |
| HPE42-S67D | 350 (5075) | 170 (45) |
Spool valve, piloted, proportional, 3-position, 4-way, motor center
US Pat. 6,554,014| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PE12-S67H | 345 (5000) | 45 (12) |
| HPE16-S67H | 350 (5075) | 95 (25) |
| PE16-S67H | 345 (5000) | 90 (24) |
| PE42-S67H | 345 (5000) | 170 (45) |
| HPE42-S67H | 350 (5075) | 170 (45) |
Spool valve, piloted, proportional, 3-position, 4-way, motor center
| Model | Pressure bar (psi) | Flow lpm (gpm) |
|---|---|---|
| PE12-S67K | 345 (5000) | 45 (12) |
| HPE16-S67K | 350 (5075) | 95 (25) |
| PE16-S67K | 345 (5000) | 90 (24) |
| PE42-S67K | 345 (5000) | 170 (45) |
| HPE42-S67K | 345 (5000) | 170 (45) |
